■Low cost and compact structure
■Dual analog input
■Overcurrent, overvoltage, overload, phase loss, short circuit protection
■Simple PLC function
■Built-in PID software function
■Output voltage regulation AVR function
Power supply | Model | Power | Output current (A) | A | B | H | W | D |
Installation dimension | Overall dimension | |||||||
Single-phase AC | 0.4S1-220V | 0.4KW | 2.1 | 60.5 | 160 | 170 | 79 | 127 |
0.75S1-220V | 0.75KW | 3.8 | ||||||
1.5S1-220V | 1.5KW | 7.0 | ||||||
2.2S1-220V | 2.2KW | 9.0 | 68 | 173 | 187 | 86 | 144 | |
3.0S1-220V | 3.0KW | 13.0 | 83.5 | 204 | 216 | 101 | 151 | |
4.0S1-220V | 4.0KW | 15.0 | ||||||
4.0S1-220V | 4.0KW | 15.0 | 93.5 | 221 | 237 | 111 | 168 | |
5.5S1-220V | 5.5KW | 20.0 | ||||||
Three-phase AC 200V-240V | 0.4S3-220V | 0.4KW | 2.1 | 60.5 | 160 | 170 | 79 | 127 |
0.75S3-220V | 0.75KW | 3.8 | ||||||
1.5S3-220V | 1.5KW | 7.0 | ||||||
2.2S3-220V | 2.2KW | 9.0 | 68 | 173 | 187 | 86 | 144 | |
3.0S3-220V | 3.0KW | 13.0 | 83.5 | 204 | 216 | 101 | 151 | |
4.0S3-220V | 4.0KW | 15.0 | 93.5 | 221 | 237 | 111 | 168 | |
5.5S3-220V | 5.5KW | 20.0 | ||||||
Three-phase AC 340V-440V | 0.4G3-380V | 0.4KW | 1.5 | 60.5 | 160 | 170 | 79 | 127 |
0.75G3-380V | 0.75KW | 2.1 | ||||||
1.5G3-380V | 1.5KW | 3.8 | ||||||
2.2G3-380V | 2.2KW | 5.1 | ||||||
2.2G3-380V | 2.2KW | 5.1 | 68 | 173 | 187 | 86 | 144 | |
3.0G3-380V | 3.0KW | 7.1 | ||||||
4.0G3-380V | 4.0KW | 9.0 | ||||||
4.0G3-380V | 4.0KW | 9.0 | 83.5 | 204 | 216 | 101 | 151 | |
5.5G3-380V | 5.5KW | 12.6 | ||||||
7.5G3-380V | 7.5KW | 16.1 | ||||||
7.5G3-380V | 7.5KW | 16.1 | 93.5 | 221 | 237 | 111 | 168 | |
11G3-380V | 11KW | 25.0 | 130 | 237 | 249 | 143 | 172 | |
15G3-380V | 15 | 32 | 188 | 305 | 324 | 209 | 192 | |
18.5G3-380V | 18.5 | 37 | ||||||
22G3-380V | 22 | 45 | ||||||
HS320
HS321
